The S-330 is a high-speed piezoelectric tip/tilt platform for precise tilting of mirrors and other optical elements in two axes. It features high dynamics, precise motion control, and short settling times. It is suitable for laser beam steering and stabilization, laser scanning, laser tuning, or image processing.
Key Features
- Precise tilting of mirrors and optics in two axes
- Mechanical angular range of 2, 5, or 10 mrad depending on the variant
- Resolution up to 20 nrad
- Resonant frequency up to 1.6 kHz with a 1" diameter mirror
- Response time of less than 1 ms for fast positioning and stabilization
- Designed for mirrors with diameters up to 50 mm
- Backlash-free, maintenance-free, and frictionless flexible guidance
- Parallel kinematics for fast and precise multi-axis motion
- Integrated SGS strain gauge sensors for position measurement
- PICMA® piezoactuators with all-ceramic insulation and long service life
